Basic Info.
Nominal Voltage
Custom
Warranty
10 Year
Nominal Capacity
100-500kwh
Cycle Life
6000cycle
Keyword
1mwh Energy Storage System Container
BMS System
Customized
Model Number
250kwh/500kwh/1mwh/Customizable
Battery Type
Lithium Ion, LiFePO4, LFP
Certificate
CE/RoHS/Un38.3/MSDS
Protection
PCS, BMS, EMS
Transport Package
Container
Specification
Customization
Trademark
Dawnice/OEM/ODM
Origin
Jiangxi Province, China
HS Code
8537209000
Production Capacity
300piece/Month
Packaging & Delivery
Package Size
180.00cm * 145.00cm * 230.00cm
Package Gross Weight
1590.000kg
Product Description
| Model | DW-ESS-100 | DW-ESS-200 |
| Parameter-BATTERY(DC) | ||
| Combination method | 1P112S | 1P224S |
| Rated Voltage | 358.4V | 716.8V |
| Voltage range(V) | 313.6-403.2 | 627.2-806.4 |
| Rated Capacity(Ah) | 280Ah | |
| Rated Energy[kWh] | 100.3kWh | 200.7kWh |
| Cycle Life | ≥6000 | |
| AC(on -grid) | ||
| Recommend input power | 50kW | 100kW |
| Rated Voltage | 400V | |
| Output | 3W+N+PE | |
| Voltage range | -15%-+10% | |
| Rated frequency | 50/60Hz | |
| AC(off -grid) | ||
| Rated power | 20 kW | 100kW |
| Rated Current | 43A | 144A |
| Rated Voltage | 380V / 400V/ 440V | |
| Rated frequency | 50/60Hz | |
| SIZE&INSTALLMENT | ||
| Dimension(WXDXH) mm | 1680*1500*1700 | 1680*2270*1700 |
| Weight 1100kg 2300kg | ||
| Environmental temperature | -20ºC~+55ºC(> 45°C power reduction) | |
| Relative humidity 0-95%non-condensing | | |
| Protection degree | IP54 | |
| Noise emission | 60dB(A)@1m | |
| Max. conversionefficiency | 95% | |
| Max.imum altitude | 4000m(derate over 2000m) | |
| Cooling Forced-air, | Intelligent fan adjustment | |
| Commun i ca t ion | Modbus-RTUCAN2.0B | |
| Display Touch screen | LCD(Optional) | |
| Communication interface | RS485/CAN | |
| Click Here Send An Inquiry To Contact Us For Catalog | ||
Schools, factories, gas stations and other commercial buildings with high energy demands can maximize energy use
Energy independence and reduced grid power demand through solar PV and battery storage. iPotisEdge provides one-stop
Find solutions for commercial and industrial facilities to save on electricity bills, reduce the risk of rising energy prices, generate additional revenue from renewable energy and reduce their environmental impact.
To be a World-Class Energy Services Provider
20+ years of experience in the Electric Power System industry. Different Brands and Types of Battery Cells. 1300+ Patents. 10+ years experience in energy storage system development. We have our own independent R&D.
Energy Management System
EMS is a centralized energy management and data monitoring center for the whole energy storage power station system Data acquisition Control function HMI
Energy Management System
EMS is a centralized energy management and data monitoring center for the whole energy storage power station system Data acquisition Control function HMI
Battery Storage System
Battery Management System(BMS) Battery Moulde&Pack Battery Rack Battery Cooling System Battery Fire Suppression System DC/AC Panel IEC/CE/GB-T certified
Power Conversion System Complete product range(30kW~4000kW) , compliant to IEEE standards and applicable to various applications. Real-time active/reactive power scheduling & LVRT functions. Advanced droop control method, up to 99% power sharing efficiency for parallel connection of voltage sources. IEC/CE/GB-T certified
2. Flexible-configuration
It can match the PCS with an AC side voltage of 900~1300V, making the system integration solutions more flexible
3. Super long life cycle,8000+ cycles
4.1CP+ sustained high power output capacity
5. High energy density equal to 7MWh in a 40 feet container
6. Cycle life enhance by 10%, temperature deviation: within 2 ºC
1. Free-installation
This product is designed from the perspective of reducing customer site work, and the overall weight of the container is designed below the maximum allowable transport weight, so it can be transported as a whole without removing the module 50% faster installation and Reduced 30% CapEx for on-site installation 15% energy density increase2. Flexible-configuration
It can match the PCS with an AC side voltage of 900~1300V, making the system integration solutions more flexible
3. Super long life cycle,8000+ cycles
4.1CP+ sustained high power output capacity
5. High energy density equal to 7MWh in a 40 feet container
6. Cycle life enhance by 10%, temperature deviation: within 2 ºC
